3 Bit Fuzz

3 Bit Fuzz

Untamed sonic mayhem

Regular price £150.00
Regular price Sale price £150.00
Sale Sold out
Shipping calculated at checkout.

3 Bit Fuzz is an experimental, multi-band bitcrusher. It's our attempt to do something a little bit different, and take some risk and try making an actually original pedal.

The signal chain splits into three paths, with each path having pre-distortion low- and high pass filters, a bitcrusher, and post-distortion filters. The pedal has 8 different modes, which tweak the cutoff frequencies for the pre- and post distortion filters, offering a wide variety of sounds. The signal chain is then finished off with a few tone-shaping controls - a treble-rolloff tone control, a mid-scoop filter, and a feature we call "Curves", which introduces an output EQ curve to the sound, which makes the pedal suitable for running either in front of an amp or directly into a power amplifier.

View full details

Daedalus Effects Series

Daedalus is a line of digital effects pedals, with the unique feature of being able to swap out the faceplates on the pedals, to re-program the device to any other effect in the series. It also features full MIDI control, Expression pedal control and it can be powered via USB (or a standard 9V DC adapter)

Features

  • 24 bit audio codec
  • Supports instrument or line-level inputs
  • MIDI 3.5mm TRS (Type-A) input
  • Expression pedal / external footswitch input
  • MIDI over USB
  • 9V DC or USB powered
  • Dual, soft-touch footswitches
  • 1.5mm thick, powder-coated steel enclosure for an extremely rugged build
  • Reversable faceplate with two different designs on each pedal
  • Ability to completely reprogram the pedal to a different effect from the Daedalus line-up
  • All effect firmware is available for free

Firmware Downloads

Go to the Firmware Page

Get More Faceplates

Web Editor

The web editor lets you control all parameters of the pedal directly from your web browser, using either a USB or MIDI connection. (The editor is still in development and more features will be added soon)

Open Web Editor

Product Details - 3 Bit Fuzz

User Manual

Download User Manual

Controls
